Code: 07005
Loading...
Features:
- No volt safety switch prevents accidental start-up.
- Choice of single speed or multi-speed switch.
- Powerful 4 pole (brush) motor geared 3:1, up to 4.5hp at the drum.
- Dynamical balanced sanding drum.
- Tough clamp bar style drum.
- High impact resistant ABS guards.
- High powered vacuum system.
- Disposable paper or cloth dust bags.
| Average Load Current | 220/240V = 8A |
|---|---|
| Approvals | CE (220/240V) |
| Abrasives | 495mm (19.5″) total length x 203mm (8″) wide abrasive sheet with notched and angled ends. Recommended grit P24 to P120. Recommended type aluminium oxide or silicon carbide, backing E or F weight paper, bonding resin over resin with antistatic additives. |
| Guards | High impact injection moulded ABS |
| Moving Parts | Sealed for life ball bearings. |
| Dust Pickup | Seated oversize alloy vacuum fan with adustable dust shoe, disposable paper dust bag or cloth bag. |
| Drive | Non-slip toothed timing belts and high precision gear cut pulleys. |
| Sanding Drum | 203mm (8″) wide aluminium extrusion with screw on moulded rubber drum cover with stainless steel backing and 2 screw abrasive clamp bar, dynamically balanced to 0 to 3g (0 to 0.106 oz) tolerance. |
| Drum RPM | Single Speed = 3,300 |
| Motor RPM | Single Speed = 8,500 |
| Switch | Single Speed – contactor type On/Off with no volt start and overload protection. |
| Model | HT8-1 |
| Off Load Current | 220/240V = 5A |
| Product Code | 7005 |
| Motor | Continuous heavy-duty AC/DC self cooling 4 brush motor. |
| Power Supply | 220/240V 50/60Hz |
| Shipping Weight | 50.0kg (110.3lbs) |
| Weight Net | 41.5kg (91.5lbs) |
| Power Cable | 7m (23′) Non-marking outer insulation. |
| Warranty | 2 years |
| Dimensions | 322mm x 940mm x 855mm (12.7″ x 37″ x 33.6″) width x depth x height Maximum dimensions with handle fully extended and dust bag in operating position. |
