Loncin LC3500i 3.5kW Silenced Petrol Inverter Generator

Code: DPTLC3500I
Loading...



Loncin LC3500A-S 3.1kW Petrol Generator – Portable Open-Frame Generator

The Loncin LC3500A-S petrol generator provides practical portable power for construction, maintenance, agricultural and backup applications. Delivering a rated output of 2.8kW and a maximum output of 3.1kW, it is suited to compatible power tools, equipment and appliances within its operating capacity.

Featuring a durable open-frame design, recoil starting, low-oil protection and a choice of 115V and 230V power outlets, the Loncin LC3500A-S offers a convenient portable power solution for professional and general-purpose applications.

Its combination of two 115V 16A sockets and one 230V 16A socket makes it particularly practical for users who operate different types of compatible site tools and electrical equipment.

Practical 3.1kW Portable Power

The LC3500A-S combines a compact open-frame design with a maximum output of 3.1kW. It can support a range of compatible tools and equipment on construction sites, in workshops, around farms and during property-maintenance work.

With a continuous rated output of 2.8kW, this petrol generator is suitable for applications where a portable power supply is required and the connected electrical load remains within the generator's capacity.

It can also provide temporary backup power for compatible equipment where the electrical requirements are appropriate for this generator.

Important: Always check the running and starting wattage of everything you intend to connect. Equipment containing motors, pumps or compressors can require considerably more power when starting than during normal operation.

Three 115V and 230V Power Sockets

The Loncin LC3500A-S petrol generator features three power outlets for connecting compatible electrical equipment.

  • 2 × 115V 16A sockets for compatible site tools and equipment
  • 1 × 230V 16A socket for compatible 230V tools and appliances

This combination supports compatible 110V-class site equipment and 230V tools or appliances. Equipment must only be connected to the appropriate outlet and remain within the generator's rated capacity.

Socket and load guidance: The generator's rated output applies to the total electrical load. Multiple sockets do not increase the generator's available power. Check the voltage, current and starting requirements of each connected appliance or tool.

Key Features and Benefits

  • 2.8kW rated output for compatible continuous electrical loads
  • Maximum output of 3.1kW for suitable temporary power applications
  • Two 115V 16A sockets for compatible site equipment
  • One 230V 16A socket for compatible electrical equipment
  • Recoil-starting system for straightforward manual starting
  • Low-oil protection helps safeguard the engine
  • Durable open-frame construction for practical portable use
  • Single-phase output for compatible electrical applications
  • Suitable for professional and general-purpose applications
  • Compact portable-power solution for work sites and maintenance tasks

Suitable Applications

The Loncin LC3500A-S 3.1kW petrol generator is suitable for a range of portable power applications when the electrical requirements of the connected equipment are within its operating capacity.

  • Construction and building sites
  • Compatible 110V site tools
  • Workshops and mobile work areas
  • Agricultural and farm applications
  • Property and grounds maintenance
  • Outdoor projects
  • Temporary power requirements
  • Compatible domestic backup equipment

Application suitability: Actual suitability depends on the combined running wattage, starting wattage and electrical requirements of the equipment being powered. Confirm compatibility before use, particularly for equipment with specific power-quality requirements.

Loncin LC3500A-S Technical Specifications

Specification Details
Brand Loncin
Model LC3500A-S
Daly Industrial Supply Product Code DPTLC3500-A
Product Type Open-frame petrol generator
Phase Single phase
Rated Output 2.8kW
Maximum Output 3.1kW
Starting System Recoil start
Socket Configuration 2 × 115V 16A sockets
1 × 230V 16A socket
Low-Oil Protection Yes
Noise Level Approximately 76dBA

Why Choose the Loncin LC3500A-S?

The Loncin LC3500A-S offers a useful balance of output, portability and socket flexibility. Its combination of 115V and 230V connections makes it particularly practical for users who operate different types of compatible equipment.

With a 2.8kW rated output and 3.1kW maximum output, the generator provides a convenient source of temporary electrical power for suitable site tools, maintenance equipment and general-purpose applications.

The recoil-starting system and low-oil protection complement its straightforward design, while the open-frame construction makes it a practical option for portable power requirements.

For users who need more output than a small leisure generator but do not require the capacity of a larger commercial machine, the LC3500A-S is an option worth considering.

Safe Generator Operation

Correct generator operation is essential for protecting users, connected equipment and the surrounding environment.

  • Operate outdoors in a suitable, well-ventilated location
  • Never operate inside homes, garages, sheds or enclosed buildings
  • Keep the generator away from doors, windows and air intakes
  • Check the running and starting wattage of connected equipment
  • Use the correct socket and suitable electrical connections
  • Protect the generator from rain and wet conditions
  • Switch off the engine and allow it to cool before refuelling
  • Follow the manufacturer's operating and maintenance instructions

Carbon monoxide warning: Petrol generators produce carbon monoxide, a poisonous gas that can cause serious injury or death. Never operate this generator indoors or in partially enclosed spaces. Keep it well away from openings through which exhaust gases could enter occupied buildings.

Electrical safety: Never connect a portable generator directly to household or building wiring. Any connection to a building's electrical installation must use suitable changeover equipment installed by a qualified electrician.

Frequently Asked Questions

What is the output of the Loncin LC3500A-S?

The LC3500A-S has a rated output of 2.8kW and a maximum output of 3.1kW.

Does the LC3500A-S provide both 110V and 230V power?

Yes. It has two 115V 16A sockets and one 230V 16A socket for compatible electrical equipment.

Is the Loncin LC3500A-S electric start?

No. The specification for this model lists a recoil-starting system.

What can the LC3500A-S power?

It may be suitable for compatible site tools, workshop equipment, agricultural applications, maintenance work and selected backup-power requirements. Suitability depends on the running and starting wattage of the connected equipment.

Is the LC3500A-S an inverter generator?

No. The Loncin LC3500A-S is a conventional open-frame petrol generator, not an inverter generator. Confirm the electrical requirements of sensitive electronic equipment before connecting it.

Does the LC3500A-S have low-oil protection?

Yes. The generator features low-oil protection designed to help safeguard the engine when the oil level becomes too low.

How many sockets does the generator have?

The LC3500A-S has three sockets in total: two 115V 16A sockets and one 230V 16A socket.

Is the Loncin LC3500A-S suitable for construction sites?

The generator can be suitable for compatible construction and maintenance equipment, provided that the total load, voltage requirements and site electrical safety requirements are met.

Can the LC3500A-S be used for home backup power?

It may be suitable for certain compatible backup-power applications. Always confirm the total electrical demand and equipment requirements before use. Connection to fixed building wiring must be arranged by a qualified electrician using suitable changeover equipment.

Can this petrol generator be operated indoors?

No. Petrol generators produce dangerous carbon monoxide exhaust. The generator must only be operated outdoors in a suitable location away from doors, windows and ventilation openings.

What is the product code for the Loncin LC3500A-S?

The Daly Industrial Supply product code is DPTLC3500-A.

Where can I enquire about the Loncin LC3500A-S in Ireland?

Contact Daly Industrial Supply in Cork on 021 450 0051 for pricing, availability and assistance with your generator power requirements.

Looking for more generator information? For frequently asked questions about generators and general operating information, please visit our Generator FAQ & Information page .

Loncin LC3500A-S Generator – Sales and Support from Daly Industrial Supply

Looking for a practical 3.1kW petrol generator for construction, maintenance, agricultural or compatible backup-power applications?

The Loncin LC3500A-S combines a 2.8kW rated output, 3.1kW maximum output, recoil starting, low-oil protection and three 115V/230V power outlets in a portable open-frame design.

Daly Industrial Supply supplies generators, equipment, spare parts and after-sales support from Cork. Our team can help assess your power requirements and determine whether the Loncin LC3500A-S is suitable for your tools, equipment or intended backup application.

Contact Daly Industrial Supply on 021 450 0051 to request a quotation or discuss your generator requirements.

Brand: Loncin. Model: LC3500A-S. Product Code: DPTLC3500-A. Rated Output: 2.8kW. Maximum Output: 3.1kW. Starting System: Recoil.

Model LC3500i
Engine Model LC170FD-3
Dimensions (mm) 579x440x510
Fuel Tank Capacity (L) 10
Displacement (cc) 212
Noise (dBA) 65
Continuing time (h) 11
Voltage Outlets (Sockets) (2 x 230V 13A)
Rated Output (Kw) 3
Max Output (Kw) 3.5
Starting system Recoil start/Electric
New Weight (Kg) 45
